10 | SHOREMASTER.COM
ACCESSORY INSTALLATION
Parts List
DESCRIPTION
PART NUMBER
QTY
ITEM
Step
100454941
Bottom Upright 32.0 100498522
Top Upright 34.0 100498923
Leg
10056792
4
Left Stringer
10037841
5
Right Stringer
100378316
Handrail 4 Step
10038442
7
Bolt Bag
10044421
-
Nut 1/4
10017971 68
Nut 3/8
100180389
Carriage Bolt 1/4 x .75
10019501610
Bolt 3/8 x 2.0
100242441 1
Bolt 3/8 x 3.0
100243241 2
Press-In Cap
100098641 3
4
12
2
3
11
6
5
9
8
1
10
11
9
7
12
QC 4-Step Dock Steps
Instructions
Part #: 1004263
Note: There are three different types of accessory brackets that
the steps can be attached to in order to be attached to your
dock. You will need two accessory brackets for the installation.
Below is a list of the three different types of brackets.
Note: In order to attach dock steps to a dock not listed above
use two 3/8" x 3-1/2" carriage bolts and two 3/8" flange nuts
(provided).
13
Step 1.
Attach steps to right and left stringer using 1/4" x 3/4"
Carriage Bolts and 1/4" Nuts provided.
Step 2
. Insert top uprights into top pockets of stringer and
secure on the bottom using 3/8" x 3" Bolts and 3/8" Hex Nuts.
Step 3
. Insert bottom uprights into bottom pockets of stringers,
fully insert legs into stringer pockets and bottom uprights, secure
the uprights and legs using 3/8" x 3" Hex Bolt and 3/8" Hex Nut.
(adjust height of legs after connecting stairs to dock frame.)
Step 4
. Connect stairs to QC accessory brackets using Carriage
Bolts and Nuts. (see QC accessory bracket instructions)
Dock Type Bracket Part Number
RS4 Dock 1006706
RS7 Dock 1006708
TS9 Dock 1006730
3 Step Ladder Shown
DESCRIPTION
PART NUMBER
QTY
ITEM
Ladder Pivot Bracket
100093221
Ladder Frame Left
100561512
Ladder Frame Right
100561613
Ladder Step
100578534
Ladder Pivot Angle
10027962
5
Bolt Bag (4 Step = 1004453, 5 Step = 1000522)
10044521
-
Nut 1/4 (4 step = qty 16, 5 step = qty 20)
10017971 26
Bolt Carriage 1/4 x 3/4 (4 step = qty 16, 5 step = qty 20)
100195012
7
Pin Snap 3/8 x 1.75
100033828
Bolt Slotted Round 3/8 x 2.0
100259329
Washer Flat 3/8
1002599
4
10
Plastic Spacer
100246921 1
Nut Nyloc 3/8-16 Brass
100180521 2
QC Pivoting Ladder
Instructions
Part #: 1006669 QC Pivoting Ladder 3 Step
Part #: 1006670 QC Pivoting Ladder 4 Step
Part #: 1006671 QC Pivoting Ladder 5 Step
Step 1
. Attach each Ladder Pivot Angle to
one Ladder Pivot Bracket and one
Accessory Connector (Sold Separately).
Secure to each with two 3/8 x 1 Carriage
Bolts and two 3/8 Flange Nuts (included with
Accessory Connector Kit) - as shown.
Step 2
. Attach each Ladder Step to the
Ladder Frame Left and the Ladder Frame
Right. Secure to Ladder Frame with two 1/4
Carriage Bolts and two 1/4 Nuts - as shown.
Step 3
. Attach the Ladder Frame Right and
Ladder Frame Left each to one Ladder Pivot
Bracket. Secure with one 3/8 x 2 Round
Slotted Bolt, two Poly Spacers, two 3/8 Flat
Washers, and one 3/8 Nyloc Nut - as shown.
Note: While the ladder is in use, secure it
down with two Snap Pins - as shown.
3
1
6
4
7
10
8
Quick-Connect Bracket
(Sold Separately)
1006706 - RS4
1006708 - RS7
1006730- TS9
5
11
2
9
10
12
