Step 1.
Bolts, 3/8" Flat Washers and 3/8" Nyloc Nuts.
Step 2.
and 1/4" Hex Nuts.
correctly, as shown.
Step 3.
tan poly.
Parts List
DESCRIPTION
PART NUMBER
QTY
ITEM
Chair Pocket
101567521
Pedestal Post101568122
Swivel Chair Base 0 Deg - Sea Sense
101680823
Hex Nut 3/8
100180344
T Handle
1000876
75
Hex Nut 1/4
100179786
Flat Washer 1/4
100257416
7
Hex Bolt 1/4 x 1.0
100239888
Washer Lock 5/16 SS
100257289
3
2
1
4
5
Step 1.
Attach one Chair Base to one Chair Sling Base (sold
separately) with four 1/4 x 1 Hex Bolts, eight 1/4 Flat Washers, four 1/4
Lock Washers, and four 1/4 Hex Nuts - as shown.
Step 2.
Attach the Chair Pocket to your dock brand's Accessory
Adaptor Brackets (Not Included in this kit).
Furniture Hardware Box
Instructions
Part #: 1015721
8
7
6
9
Note: Part #: 1015685 - Set of 2 Chairs, one table, an umbrella, and hardware box.
Connect Furniture Hardware Pocket to accessory bracket (Sold Separately)
according to accessory bracket instructions.
Note: On ShoreMaster Infinity Dock Accessory Connectors Two T-Handles are
required to clamp each Chair or Table to the dock frame.
Dock Type Bracket Part Number
RS4 Dock 1006706
RS7 Dock 1006708
RS9 Dock 1006730
Poly Dock 1006608
Note: Furniture Hardware Pocket will be attached to one of four different type of
Accessory Dock Connectors in order to be attached to your dock. Below is a list
of the four different types of docks and the required bracket.
Step 3.
Insert one Pedestal Post into the Chair Pocket and secure with
two 3/8 Nuts and two T-Handles - as shown.
Step 4.
Insert the Chair Base into the Pedestal Post.
CAUTION: Before use, make sure all connections are properly
tightened. Periodically check all connections.
