Shotoku TSA75 - Removal of the Middle Brace for TSA75 and TDA75; How to Attach Footpads and Floor Spreader

To Next Page

To Previous Page

SH series Tripods Operation Manual

4RemovaloftheMiddleBraceforTripodTSA75andTDA75



Screw

Middle Brace



Whenyouattachtheoptionalfloorspreaderandmiddlespreader,please

  removethemiddlebracefromthelegs.Themiddlebracewillremove

  fromthelegsbyremovingtherightandleftsidesscrewsatthetip.Please

  removethreepositionsatthesameway.



5HowtoattachFootpadsandFloorSpreader



RubberHook



Putthespikeofleg-tipontherollerofFootpadsandhookaRubber

Hookontheleg-tip.PleasealsoattachaFloorSpreaderinthesameway.


