1 Content organisation and consultation methods.
1.1 Symbols.
Indicates hazardous situations and warnings. Carefully read the parts of the user manual marked with
this symbol.
Indicates that work must not be performed on live electrical devices. This work may only begin after all
suitable safety measures required by current international and/or national regulations are taken.
1.2 Notes on graphics.
Used the following printing types:
• glossary of terms: italic;
• the words "product", "customer manual" and "installation manual" highlighted.
1.3 Glossary.
1. Pump: electromechanical device used to move water (Fig. 1).
Fig. 1
2. Inlet: product input (Fig. 2, IN).
Fig. 2
3. Outlet: the product’s exit (Fig. 3, OUT).
Fig. 3
4. Flowrate: the amount of fluid (water) that crosses a section in a unit of time.
5. Head: this is the maximum distance that a pump can lift water for.
6. Flooded: if the pump is positioned at a level below the water level to be sucked.
7. Dry operation: means the product’s operation without water.
8. Residual Current Device: (RCD) also called fuse, it is an electro-technical device able to cut off the
circuit in the event of fault.
9. Hydraulic parts: components used to create the system where the product is used (pipes, valves,
couplings, hose connections, etc.).
10. Pool: artificial tank filled with water general intended for swimming or other aquatic activities.
11. Filter: a device where the water flowing in order to retain and/or eliminate the solid particles
suspended.
12. Filter media: filtering material, contained in the filter, responsible for filtering.
13. Skimmer: a filter that keeps the swimming pool surface clean.
14. Power plug: mechanical connector that can be inserted in a complementary electrical socket
(power outlet).
15. Maximum working pressure: maximum pressure the product is able to sustain during operations.
16. Multifunctional valve: device used to regulate the water flow (Fig. 4, # 1).
