Shure Incorporated
5/7
Specifications
Type
Dynamic (moving coil)
Frequency Response
60 to 11,000 Hz
Polar Pattern
Cardioid
Output Impedance
Dual. "Low" is 260 ohms for connection to microphone inputs rated at 19 to 300 ohms and "High" for con
nection to high-impedance microphone inputs.
Sensitivity
at 1kHz, open circuit voltage, dependent on impedance setting
LOW -57.5 dB (1.3 mV)
HIGH -38.5 dB (12 mV)
Switch
Press-to-Talk
Switch
lockable, for microphone and an external relay or control circuit. Microphone circuit normally shorted
in both high and low impedance.
[1]
