SPECIFICATIONS

Frequency Response

20 to 20,000 Hz ± 0.5 dB

Impedance

Input: 100 kW

Output: 300 W

Attenuation

50 dB

Maximum Input Signal Level

40 dBV

Connectors

Input: 3-socket female XLR

Ouput: 3-pin male XLR

Case

Full magnetic shield, steel with gray

enamel nish

Dimensions

19 m m (3/4 in.) diameter; 114 mm

(4 1/2 in.) long
