MODEL PE588
Type:
Frequency
Response:
Impedance:
Output Level
(at 1,000
Hz):
Open Circuit
Voltage:
Phasing:
Switch:
SPECIFICATIONS
Dynamic, Cardioid (Unidirect~onai)
FIGURE
1
M~clophone ~mpedarlce
IS
"H~gh" lor
connection
to h~gh-
Impedance m~crophone inputs.
-59
dB (1.11 mV)
(0 dB
=
1 volt per microbar)
Positive pressure on diaphragm produces positive voltage
on Pin 1 (see Figure
2
and Page
4).
CARTRIDGEmlWSFORHER
SWITCH
CONNECTOR
CABLE
FIGURE
2
Built-in On-Off switch with lockplate installed in unlocked
position. To
lock sw~tch in On position, move to On posi-
tion, loosen screw on lockplate and turn lockplate
180".
Retighten screw.
\
GUARANTEE
This Shure product is guaranteed in normal use to be free from electrical and
mechanical defects for a period of one year from date of purchase. Please re-
rain proof of purchase date. This guarantee includes all parts and labor. This
guarantee is in lieu of any and all other guarantees or warranties, express or
implied, and there shall be no recovery for any
consequentlal or incidental
damages.
SHIPPING INSTRUCTIONS
Carefully repack the unit and return it prepaid to:
Shure Brothers Incorporated
Attention: Service Department
1501 West Shure Drive
Prl~ngton Heights, Illinois 60004
If
outs~de the United States, return the unit to your dealer or Authorized Shure
Service Center for repair. The unit will be returned to you
prepa~d.
