14
RED
IMPEDANCE
CONVERTER
CONDENSER
CARTRIDGE
BLK
SHIELD
3
4
2
1
S
G
D
Audio Out
+5 Vdc
CONDENSER CAR-
TRIDGE
IMPEDANCE
CONVERTER
RED
BLK
SHIELD
GROUND
AUDIO OUT
+5 Vdc
S
G
D
+
WL50/MC50 and WL51/MC51 SERIES MICROPHONE
WIRING DIAGRAM WITH TA4F CONNECTOR
WL50X SERIES MICROPHONE WIRING DIAGRAM
(UNTERMINATED)
FIGURE 3
FIGURE 4
