16
99 mm
(3.89 in.)
20 mm DIA.
(.79 in.)
14 mm
(.55 in.)
19 mm DIA.
(.75 in.)
1.52 m (5 ft.) for WL50/MC50 and WL51/MC51 Series
5.8 mm (.23 in.)
3.04 m (10 ft.) for WL50X/WL51X Series
5.8 mm (.23 in.)
PREAMPLIFIER DIMENSIONS
FIGURE 6
MICROPHONE AND CABLE DIMENSIONS
FIGURE 7
