SIA CH61 - Chimney and Ducting Installation; Mounting Chimney Brackets; Fixing and Securing Ducting

10
Fig. 12
Fig. 13 Fig. 14
Mount chimney brackets Fix ducting (seal joint)
Mount the chimney Adjust and secure the chimney
Fig. 11
The metal casing of this appliance has been coated with a preservative to protect it during transport and storage.
This should be removed during installation by using a non-abrasive stainless steel cleaner. Always follow the
instructions given with the cleaner being used.
