TMX Flail Mower
- 3 -
INDEX
1. INTRODUCTION 5
1.1 SOME NOTES REGARDING THE USER MANUAL 5
1.2 DECLARATION OF CONFORMITY 6
1.3 LIST OF RESIDUAL RISKS 7
1.4 GENERAL DELIVERY NOTES 8
1.5 FLAIL MOWER IDENTIFICATION AND MANUAL CODE 9
1.6 INTENDED USE 9
1.7 GENERAL DELIVERY NOTES 10
1.8 FLAIL MOWER COMPOSITION 11
1.9 STANDARD AND OPTIONAL SET-UPS 12
2. SAFETY 13
2.1 DEFINITIONS (UNI EN ISO 12100-1:2009) 13
2.2 CONVENTIONAL SYMBOLS 13
2.3 SAFETY PRESCRIPTIONS 14
2.4 OPERATOR REQUIREMENTS 14
2.5 CLOTHING AND PPE 14
2.6 MACHINE USE 15
2.7 SAFETY DEVICES 15
2.8 REASONABLY PREDICTABLE INCORRECT USE 15
2.9 HYDRAULIC SYSTEM 16
2.10 ZERO ENERGY STATE 16
2.11 LOCATION OF DECALS ON THE MACHINE 17
3. UNLOADING AND UNPACKING THE FLAIL MOWER 19
3.1 FLAIL MOWER PROTECTED BY HEAT-SHRINK FILM 19
3.2 FLAIL MOWER IN WOODEN CRATE 20
4. TECHNICAL FEATURES 22
5. START-UP 23
5.1 3-POINT HITCH CONNECTION 23
5.2 CARDAN SHAFT CONNECTION 24
5.3 CHECK THE STABILITY OF THE TRACTOR-FLAIL MOWER ASSEMBLY 26
5.4 ROAD TRANSPORT 26
6. ADJUSTMENTS 27
6.1 WORKING HEIGHT 27
6.3 RAKES 29
6.5 BELT TENSIONING 30
6.6 PREVENTIVE MAINTENANCE 30
6.7 USE 30
7. STOPS 32
8. ORDINARY MAINTENANCE 33
8.1 CHECKING AND CHANGING THE OIL IN THE MULTIPLIER GEARBOX 34
8.2 GREASING 35
8.3 REPLACING THE TRANSMISSION BELTS 36
8.4 REPLACING KNIVES/HAMMERS 37
9. CARDAN SHAFT 38
10. CLEANING 39
