Sidewinder 6500 ESP - Remote Start Primary Harness, 5-Pin Connector; Heavy Gauge Relay Satellite; Remote Start Secondary Harness (H3), 6-Pin Connector

8 © 2000 Directed Electronics, Inc. Vista, CA
remote start primary harness, 5-pin connector
______
______
______
______
______
heavy gauge relay satellite key switch interface
______
______
______
______
______
______
remote start secondary harness (H3),
6-pin connector
______
______
______
______
______
______
BLACK/WHITE (-) NEUTRAL SAFETY SWITCH INPUT
VIOLET/WHITE TACHOMETER INPUT WIRE
BROWN (+) BRAKE SHUTDOWN WIRE
GRAY (-) HOOD PINSWITCH INPUT, ZONE 1
BLUE/BLACK (-) 200 mA OPTIONAL THIRD IGNITION OUTPUT
BLUE (-) 200 mA STATUS/FACTORY RE-ARM OUTPUT
H3/1
H3/2
H3/3
H3/4
H3/5
H3/6
PINK/WHITE (+) OUTPUT TO SECOND IGNITION CIRCUIT
PURPLE (+) OUTPUT TO STARTER CIRCUIT
ORANGE (+) OUTPUT TO ACCESSORY CIRCUIT
PINK (+) OUTPUT TO PRIMARY IGNITION CIRCUIT
RED (+) HIGH CURRENT 12V INPUT
RED (+) HIGH CURRENT 12V INPUT
1
2
3
4
5
6
PURPLE (-) 200 mA STARTER RELAY TURN-ON
ORANGE (-) 200 mA ACCESSORY RELAY TURN-ON
PINK (-) 200 mA IGNITION RELAY TURN-ON
YELLOW (+) IGNITION INPUT TO ALARM
RED (+) CONSTANT POWER
1
2
3
4
5
