This document is a user guide for the SIDIZ Ringo chair, designed specifically for growing children. The chair offers a range of adjustable features to ensure a perfect fit as the child grows.

Function Description

The SIDIZ Ringo chair is a children's chair with several adjustable functions to accommodate different stages of growth and ensure proper posture. Its primary functions include:

Growing Function: The chair's backrest and seat depth can be adjusted to four different levels, allowing it to adapt to the child's changing height and body dimensions. This adjustment is made by pulling round levers on both sides of the backrest outwards and then moving the backrest up or down. It is recommended that an adult perform this adjustment while the child is seated.
Seat Height Adjustment: The seat height can be easily adjusted to achieve the desired ergonomic position. To elevate the seat, the user lifts a lever and releases it at the desired height. To lower the seat, the user sits on the center of the chair, lifts the lever, and releases it when the desired height is reached.
Sit-Brake Casters: The chair is equipped with sit-brake casters. These casters automatically stop when an appropriate amount of weight is applied to the chair. This feature helps to stabilize the chair, promoting a healthy posture and preventing unwanted movement while the child is seated.
Removable Footrest: The Ringo chair includes a footrest that can be removed when the user no longer requires additional foot support. This allows for greater flexibility as the child grows and their feet can comfortably reach the floor. The footrest is secured with three screws, which can be removed using an Allen wrench.

Important Technical Specifications

Based on the provided dimension diagram, the SIDIZ Ringo chair has the following approximate dimensions (in inches, with millimeters in parentheses):

Seat Height Range: 14.8 - 17.1 inches (375 - 435 mm)
Overall Chair Height Range (with backrest adjustment): 30.9 - 34.8 inches (+3.9 inches) (785 - 885 mm (+100 mm))
Seat Depth Range (with growing function): 17.3 - 21.3 inches (440 - 540 mm)
Overall Chair Width: 22.8 - 26.8 inches (+2.4 inches) (580 - 680 mm (+60 mm))
Seat Width: 17.3 inches (440 mm)
Base Diameter: 20.3 inches (515 mm)
Warranted Weight Capacity: 113 kg (or less).

Usage Features

The SIDIZ Ringo chair is designed for ease of use and adaptability for children.

Intuitive Adjustments: The growing function and seat height adjustments are designed to be straightforward, using levers for quick changes.
Safety Features: The sit-brake casters enhance safety by preventing the chair from rolling when the child is seated, promoting stability and good posture.
Long-term Usability: The adjustable features allow the chair to be used for an extended period, adapting to the child's growth without needing frequent replacements. The removable footrest further extends its usability.

Maintenance Features

The user guide emphasizes several important warnings and precautions to ensure the safe and proper use of the chair, which can be considered aspects of "maintenance" in terms of preserving its functionality and user safety. While specific cleaning instructions are not provided, the warnings highlight practices to avoid damage and injury:

Safety Warnings and Precautions:

Do not stand on the chair: Risk of injury due to caster movement.
Do not sit on the edge of the chair: Risk of overturn.
Use for intended purpose only: Avoid using the chair for purposes other than its design.
Adhere to weight capacity: The chair is warranted for 113kg or less. Exceeding this may cause damage.
Avoid excessive impact while tilted: May damage the chair.
Do not sit astraddle on seat or backrest: Risk of injury or overturn.
Do not sit astraddle on armrest: To prevent slipping.
Do not press the backrest when someone is seated: Could cause discomfort or injury.
Do not sit on the chair when someone is under it: Risk of injury.
Do not push the chair when someone is seated: Risk of injury.
Avoid rotating the chair when someone is seated: Risk of injury to the person.
One person per chair: Do not use the chair for more than two people (likely a typo, intended to be "more than one person").
Ensure toe safety: When sitting without shoes, ensure toes are safe from caster movement.
Do not sit facing the headrest: Risk of overturn.
Keep fingers clear: Do not put or insert fingers into any part or gap of the chair.
Proper seating posture: Do not use the chair with maximum tilt and legs on a desk or other objects.
Avoid excessive tilting: Do not tilt the body excessively forward, left, or right when seated.
Prevent overturn during rotation: The chair may overturn if rotated while legs are on the seat.
Not for exercise: Do not use the chair for exercises like push-ups.
Do not lean on the chair when standing: Risk of injury due to unexpected caster movement.
Do not throw or kick the chair: To prevent damage.
Do not astraddle on the tablet (if applicable): May cause breakage.
Do not walk across chairs: General safety.
Proper leg placement: Do not put legs under the base and tilt forward, as this may cause overturn.
Read the manual: Users should fully understand the chair's usage before operating it.
Warranty limitations: The manufacturer does not apply warranty for injuries, dangers, or damages caused by neglecting these warnings.

These warnings collectively form the "maintenance" guidelines by instructing users on how to prevent damage, ensure longevity, and maintain a safe environment while using the SIDIZ Ringo chair.
