Siemens CF62 Service Repair Documentation

Company Confidential s Com
Copyright 2005© Siemens AG
Page
8 of 10
Service Repair Documentation Level 2.5 - CF62, CF62R, CF63
5 Connector Battery
Fault Symptoms
Customer: GRT:
Mobile does not switch on No connection to GRT
Battery connector
Problems
Check the status of the
battery connector visually
okay
not okay
Level 2 Repair
Exchange
Battery connector
- check for twisted or
bended contacts
- check for dry joints
Use the resistor test
function of a multimeter
to check connection
between spring
contacts and soldering
contacts. The value
must be ~0Ω
Watch for oxidation and
damaged pads of the battery
connector
not okay
okay
okay
SCRAP has to be
send separately to
WSC
not okay
Connector BATTERY
Use hot air blower to remove defective component. Avoid excessive heat! Watch surrounding components!
Resolder new component afterwards.
E-commerce order number: L36334-Z97-C336
Soldering temperature: 240 - 255°C
IRIS Diagnose Code: 13000 Battery/Mechanical Damage
