Sublist of the System Status List (SSL)
150
S7-400 Instruction List
A5E00267845-01
Sublist of the System Status List (SSL), continued
SSL-ID Information Functions
Assignment between process image partitions and OBs
0025 Assignment betweeen all process image partitions and OBs within the CPU
0125 Assignment between a process image partition and the corresponding OB
0225 Assignment between an OB and the corresponding process image partitions
0F25 Only SSL partial list header information
Communication Status Data
0132 Status data for a communication unit
0232 Status data for a communication unit
H CPU Group Information
0071 Information on the current status of the H system
0F71 Only partial list header information
Status of the Module LEDs
0174 Status of one LED
Switched DP Slaves in the H System
0C75 Communication status between the H system and a switched DP slave
