Execution Times with Indirect Addressing1
20
S7-400 Instruction List
A5E00267845-01
The execution time for loading the address of the instruction from the various areas is shown in the following table.
Address is in ... Execution Time in s
CPU 412 CPU 414 CPU 416 CPU 417
Bit memory area M
Word
Double word
0.2
0.2
0.12
0.12
0.08
0.08
0.06
0.06
Data block DB/DX
Word
Double word
0.3
0.3
0.18
0.18
0.12
0.12
0.12
0.12
Local data area L
Word
Double word
0.2
0.2
0.12
0.12
0.08
0.08
0.06
0.06
AR1/AR2 (area-internal) 0.0 * 0.0 * 0.0 * 0.0 *
AR1/AR2 (area-crossing) 0.0 * 0.0 * 0.0 * 0.0 *
Parameter (word) ... for:
S Timers
S Counters
S Block calls
0.4
0.4
0.4
0.24
0.24
0.24
0.16
0.16
0.16
0.15
0.15
0.15
Parameter (double word) ... for
Bits, bytes, words
and double words
0.4 0.24 0.16 0.15
* Address registers AR1/AR2 do not need to be loaded in separate cycles for addressing.
The pages that follow contain examples for calculating the instruction run time for the various indirectly addressed instructions.
