E
Manuelle Verstellung
Manual adjustment
Positionnement manuel
Manuell justering
Handmatige verstelling
Posizionamento manuale
Käsiohjaus
Posicionamiento manual
Manuel justering
动操作
수동 조작
手動操作
P
U
S
H
P
U
S
H
2'
4626Z01
Push
3'
L << 67 mm
L >> 67 mm
2
Push
1
3
F
Einstellung: Hilfsschalter A, B
Setting: Auxiliary switches A, B
Réglage: Contact auxiliaire A, B
Inställning: Hjälpkontakt A, B
Instelling: Hulpschakelaar A, B
Taratura: Contatto ausiliaro A, B
Asettelu: Apukytkin A, B
Ajuste: Contacto auxiliar A, B
Indstilling: Hjælpekontakt A, B
设定辅助开关
보조 스위치의 설정
補助スイッチの設定
4626Z26
1
2
4
b
Push
A
B
A
B
1 x click
S1 S1 S4 S4
S2 S3 S2 S3 S5 S6 S5 S6
(Q12)
(Q14)
(Q14)
(Q12)
(Q22)
(Q24)
(Q22)
(Q24)
(Q11)
(Q11)
(Q21)
(Q21)
85°
20° 30° 70° 90°
5
°
0
°
0
°
3
Werkeinstellung
Factory setting
Préreg à l'usine
Fabriksinställning
Fabrieksmatig ingestelde
Alla consegna
Tehdasasetus
Ajuste de fábrica
Fabriksindstillet
A = 5°
B = 85°
80
70
60
50
B
90
Aux Switch
Adjustment
20
30
40
10
20
40
A
70
A
B
A
B
공장조정
原厂
工場設定
G
Massbild
Dimensions
Encombrement
Måttuppgift
Maatschets
Ingombri
Mittapiirros
Dimensiones
Målskitse
尺寸
외형 치수
外形寸法
Building Technologies / HVAC Products 4 319 2685 0 h M4626 28.10.2005 7/10
min. 7
300
73
85,8
m
a
x
.
9
5
°
900
min. 100
min. 60
min. 200
20
15,5
210
2
35,4
3
4626M03
100
27,6
16
197
Ø 8... 25,6 mm
6... 18 mm
max.17,5
P1...P3
1...9
S1...S6
Taptite
M6 x 16
6x ø4,
4
67.5
35,4
ø
13
230
71
150
4x8,5
4x ø5
24,8
61,5
Masse in mm
Dimensions in mm
Dimensionsein
mm
Mått i mm
Afmetingen in mm
Dimensioni in mm
Mitat mm
Dimensiones en
mm
Mål i mm
单位 mm
mm
単位 mm
