Technical data
General unit data
Mains voltage (rated voltage)
For grounded and non-grounded networks
∂
LFSx.xxA1
120 V AC
∂
LFSx.xxA2
(also suitable for 100 V AC networks).
230 V AC
Mains frequency
50...60 Hz
Internal consumption
5 VA
Rated surge voltage
Overvoltage category III:
4 kV for the entire LFS1 unit
2.5 kV for the creepage distances or air gaps
due to voltage limitation measures
Basis of calculation for air gaps and
Overvoltage category III and degree of
creepage distances
contamination 2 for 230 V AC in accordance
with
DIN EN 60730-1:
- Reinforced insulation between terminal
areas 1...7 and 9...12
- Normal insulation between terminal areas
9...10 and 11...12
External fuse (optional)
Max. T6.3H250V to IEC 60127-2
Internal fuse for terminals 11 / 12 (fuse
T1.6L250V to IEC 60127-4
cannot be replaced)
External current limitation for terminals 9 /
Example: External fuse T1.6A
10
Permissible mounting position
Optional
Weight
∂
LFS1.11A1
115 g
∂
LFS1.11A2
115 g
∂
LFS1.21A1
148 g
∂
LFS1.21A2
144 g
Safety class
To DIN EN 60730-1:
∂
Safety class I
For applications without safe separation.
Protection against electric shock is achieved
through double or reinforced insulation.
Provision for the protective earth connection
is made in the plug-in base AGK11.7. When
replacing LAE10 / LFE10 with KF8896 and
LFS1, the maximum safety class that can be
∂
Safety class II
achieved is I.
For applications with safe separation.
Protection against electric shock is achieved
through double or reinforced insulation.
Degree of protection
IP40, to be ensured through mounting
Degree of contamination
Degree of contamination 2 to DIN EN 60730-1
Software class
Class C to DIN EN 60730-2-5
2-channel structure
Minimum flame safeguard self-test frequenc
2 x per second for continuous operation with
ionization probe or RAR9
Detection time in the event of loss of flame
Max. 1 s for LFS1 (including flame detector)
Reaction time in the event of loss of flame
Max. 1 s for LFS1 with LEC1
Voltage output at terminal 7
DC 0…10 V
Increment DC 40 mV
