Mounting notes
∂ Ensure that the relevant national safety regulations are complied with
∂ The flame safeguards can be mounted in any position on the burner, in the
control cabinets, or on the control panels
∂ The plug-in base AGK11.7 is available for mounting and is designed for cable
entry from the front, the side, or below.
4 earth terminals provide connections for the earth conductors of burner plant
components such as the ignition transformer. The flame safeguards
themselves are double-insulated; refer to the Installation notes chapter
∂ The separating plate must be connected so that it is flat / level with the plug-in
base; refer to red hatched area
77
82
z0
7/
11
15
∂ The separating plate must only be plugged into terminal 8
6 7 8 9 10 11 2
1
77
8
2z
0
6/
11
15
6/40
