Siemens S3 User Manual

3ZX1012-0RV17-4AU1 3
3RV1902-1D
3RV1902-1A
3
1
1
2
L1 ,L2, L3
T1, T2, T3
D1,D2,C1,C2; NO/NC
3RV19..-1 3RV19..-2
4 ... 6 Nm
35 ... 53 lbf.in
∅ 5 ... 6 mm/PZ2
0,8 ... 1,2 Nm
7 to 10.3 lbf.in
—
2 x 2,5 ... 16 mm²
2 x 0,5 ... 1,5 mm²
2 x 0,75 ... 2,5 mm²
2 x 0,25 ... 2,5 mm²
2 x 2,5 ... 35 mm²
1 x 2,5 ... 50 mm²
2 x 0,5 ... 2,5 mm² 2 x 0,25 ... 1,5 mm²
2 x 10 ... 50 mm²
1 x 10 ... 70 mm²
—— —
AWG
2 x 10 to 1/0
1 x 10 to 2/0
AWG 2 x 18 to 14 2 x 24 to 14
min
22
4
17
10
17
10
17

Siemens S3 Specifications

General

Rated voltage	230/400V AC
Tripping characteristic	B, C, D
Breaking capacity	10kA
Standards	IEC 60898-1
Number of poles	1, 2, 3, 4
