Description of the device
2.4 LED display
SCALANCE M874, M876
Operating Instructions, 08/2018, C79000-G8976-C331-08
25
LED
Status
Meaning
DI OFF
Digital input inactive
ON
Digital input active.
DO OFF
Digital output inactive
ON
Digital output active.
