Connecting up
4.5 Digital input/output
SCALANCE M874, M876
Operating Instructions, 08/2018, C79000-G8976-C331-08
51
Digital output
The 2-pin terminal block has the following assignment:
DO+
Relay 24 VDC / 1 A
DO-
Relay 24 VDC / 1 A
