Technical specifications
6.5 LTE router SCALANCE M876-4 (NAM)
SCALANCE M874, M876
82 Operating Instructions, 08/2018, C79000-G8976-C331-08
Permitted ambient conditions
Ambient temperature During operation Without air flow and with a clearance at the side
of 5 cm to the neighboring device:
-20 ℃ to +60 ℃
Without clearance at the side and an air flow of
0.5 m/s (only with the "LTE only" mode)
During transporta-
-40 ℃ to +70 ℃
≤ 95% at 25 °C, no condensation
Design, dimensions and weight
Installation options
• Installation in a 19" rack
• Mounting on a DIN rail
• Mounting on an S7-300 standard rail
• Mounting on an S7-1500 standard rail
• Wall mounting
• Mounting on a pedestal
Installation direction Vertical (ventilation openings at the top and
