Description
3.1 Overview of the product characteristics
SCALANCE X-200
66 Compact Operating Instructions, 12/2010, A5E00813159-11
Table 3- 2 Overview of the connection options
Fast Ethernet
10/100 Mbps
Device type SCALANCE
XF204 X208
and
XF208
X216 X224 X204-2
and
XF204-2
X206-1
and
XF206-1
X212-2 X204-2LD X206-1LD X212-2LD
TP (RJ-45) 4 8 16 24 4 6 12 4 6 12
Fiber
multimode
(BFOC)
- - - - 2 1 2 - - -
Fiber
single mode
(BFOC)
- - - - - - - 2 1 2
Fiber
POF / PCF
(SC-RJ)
- - - - - - - - - -
The following
ports are set as
ring ports when
supplied
P1, P2 P1, P2 P1, P2 P1, P2 P5, P6 P1, P2 P13, P14 P5, P6 P1, P2 P13, P14
Table 3- 3 Overview of the connection options for IRT devices
Fast Ethernet
10/100 Mbps
Device type SCALANCE
X202-2IRT X204IRT XF204IRT X204IRT
PRO
X202-
2P
IRT
PRO
X201-
3P IRT
PRO
X202-
2P IRT
X201-3P
IRT
X200-4P IRT
TP (RJ-45) 2 4 4 - - - 2 1 -
IE RJ-45 Plug PRO - - - 4 2 1 - - -
IE SC RJ Plug PRO - - - - 2 3 - - -
Fiber multimode
(BFOC)
2 - - - - - - - -
Fiber single mode
(BFOC)
- - - - - - - - -
Fiber POF / PCF
(SC-RJ)
- - - - 2 3 2 3 4
The following ports
are set as ring ports
when supplied
P3, P4 P1, P2 P1, P2 P1, P2 P3,
P4
P3, P4 P3, P4 P3, P4 P3, P4
