Technical Specifications
7.1 Technical specifications
SCALANCE X-200
96 Compact Operating Instructions, 12/2010, A5E00813159-11
Table 7- 2 Ports
Device type
SCALANCE
Attachment of end devices
or network components
over twisted pair
Attachment of end devices
or network segments over
fiber-optic cable
Connector for power
supply
Connector for
signaling contact
XF204 4 x RJ-45 jacks with MDI
X pinning 10/100 Mbps
(half / full duplex)
- 1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
X208 8 x RJ-45 jacks with MDI-
X pinning 10/100 Mbps
(half / full duplex)
- 1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
XF208 8 x RJ-45 jacks with MDI
X pinning 10/100 Mbps
(half / full duplex)
- 1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
X216 16 x RJ-45 jacks with
MDI-X pinning
10/100 Mbps (half / full
duplex)
- 1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
X224 24 x RJ-45 jacks with MDI-
X pinning 10/100 Mbps
(half / full duplex)
- 1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
X204-2 4 x RJ-45 jacks with MDI-
X pinning 10/100 Mbps
(half / full duplex)
2 x 2 BFOC sockets
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
XF204-2 4 x RJ-45 jacks with MDI
X pinning 10/100 Mbps
(half / full duplex)
2 x 2 BFOC sockets
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
X206-1 6 x RJ-45 jacks with MDI-
X pinning 10/100 Mbps
(half / full duplex)
1 x 2 BFOC sockets
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
XF206-1 6 x RJ-45 jacks with MDI
X pinning 10/100 Mbps
(half / full duplex)
1 x 2 BFOC sockets
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
X212-2 12 x RJ-45 jacks with
MDI-X pinning 10/100
Mbps (half / full duplex)
2 x 2 BFOC sockets
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
X204-2LD 4 x RJ-45 jacks with MDI-
X pinning 10/100 Mbps
(half / full duplex)
2 x 2 BFOC sockets
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
X206-1LD 6 x RJ-45 jacks with MDI-
X pinning 10/100 Mbps
(half / full duplex)
1 x 2 BFOC sockets
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
X212-2LD 12 x RJ-45 jacks with
MDI-X pinning 10/100
Mbps (half / full duplex)
2 x 2 BFOC sockets
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
X202-2IRT 2 x RJ-45 jacks with
MDI-X pinning 10/100
Mbps (half / full duplex)
2 x 2 BFOC sockets
(100 Mbps, full duplex to
100BaseFX)
1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
X204IRT 4 x RJ-45 jacks with MDI-
X pinning 10/100 Mbps
(half / full duplex)
- 1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
XF204IRT 4 x RJ-45 jacks with MDI-
X pinning 10/100 Mbps
(half / full duplex)
- 1 x 4-pin plug-in terminal
block
1 x 2-pin plug-in terminal
block
X204 IRT PRO 4 x RJ-45 jacks with MDI-
X pinning 10/100 Mbps
(half / full duplex)
- 2 x 5-pin Power Plug Pro
connectors (male)
1 x 5-pin b-coded M12
connector (male)
