Description of the device
2.2 Device views
SCALANCE XB-200
Operating Instructions, 09/2015, C79000-G8976-C359-03
13
2.2
Device views
2.2.1
Device view of a SCALANCE XB208
The following figure shows an overview of the components of the SCALANCE XB208.
Electrical ports with port LEDs
Power supply with connector for grounding
Serial interface
"RESET" button (rear)
Fault LED
