Technical specifications
8.10 SFP technical specifications
SCALANCE X-300
Operating Instructions, 02/2012, A5E01113043-12
217
Table 8- 132 Electrical data: Power supply, current consumption and power loss
Device:
Transceiver
(Variant) Effective power loss *)
SFP991-1 (1 x 100 Mbps, LC port
optical, multimode glass, up
to max. 3 km)
0.36 W
SFP991-1LD (1 x 100 Mbps, LC port
optical, single mode glass,
up to max. 26 km)
0.39 W
SFP991-1LH+ (1 x 100 Mbps, LC port
optical, single mode glass,
up to max. 70km)
0.47 W
SFP992-1 (1 x 1000 Mbps, LC port
optical, multimode glass, up
to max. 750m)
0.33 W
SFP992-1LD (1 x 1000 Mbps, LC port
optical, single mode glass,
up to max. 10km)
0.41 W
SFP992-1LH (1 x 1000 Mbps, LC port
optical, single mode glass,
up to max. 40km)
0.45 W
SFP992-LH+ (1 x 1000 Mbps, LC port
optical, single mode glass,
up to max. 70km)
0.50 W
SFP992-1ELH (1 x 1000 Mbps, LC port
optical, single mode glass,
up to max. 120km)
0.63 W
*) Note: SFP values in 25 °C environment.
Note
Fusing of transceivers
The SFP transceivers do not have fuses. The fuse is in the modular device (M).
Note
Signaling contact and media modules
The SFP transceivers do not have a signaling contact. The signaling contact is on the
modular device (M).
