Siemens SCALANCE XR324-12M User Manual

Description of the device
4.2 Product groups
SCALANCE X-300
74 Operating Instructions, 02/2012, A5E01113043-12
Slot number S1 S2
Media
modules used
- MM991-2 (SC) MM991-2 (SC)
Port number P1 *
1
) P2 *
1
) P3 *
1
) P4 *
1
) P5*
1
) P6*
1
) P7*
1
) P8*
1
) P1*) P2*) P1*) P2*)
Slot number S3 S4
Media
modules used
- MM991-2 MM991-2
Port number P9 *
1
) P10
*
1
)
P11*
1
) P12*
1
) P13*
1
) P14*
1
) P15*
1
) P16*
1
) P1*) P2*) P1*) P2*)
Connection type
electrical
Fast Ethernet port → no marking
Gigabit Ethernet port → marking *
1
)
Connection type
optical
Fast Ethernet port → marking *
2
)
Gigabit port → marking *
3
)
Connection type
Module slot
Type of attachment depending on module used → marking*)
