Technical specifications
6
CP 1623
The following technical specifications apply to the CP 1623 communications processor:
Data transmission
Transmission rate
• 10/100 Mbps (half/full duplex)
• 1000 Mbps (full duplex)
Interfaces
Connection to 10BaseT/100BaseTx/ 1000BaseT
RJ-45 ports (two)
Connector for PG/PC
PCI Express x1; can also be operated in x4, x8 or x16 slots.
Voltage
PCIe power supply
3.3 VDC
12 VDC
External power supply
Rated voltage
12 to 24 V DC
Limit voltages
minimum 10.5 VDC
maximum 32 VDC
Current consumption
at 3.3 VDC
maximum 0.85 A
at 12 VDC
maximum 0.4 A
Permitted ambient conditions
Operating temperature
5 … + 55 °C
Transportation/storage temperature
- 20 ... + 60 °C
