10
Optional accessories (order from the after-sales service using the order number, depending on the model)
Washer-dryer stack connection set
The dryer can be placed on top of a suitable washing machine with the same width and depth to save space. The dryer must be fastened to the
washing machine using this connection set. WZ 20400: with pull-out worktop.
Platform
For easier loading and unloading. The basket contained in the drawer can be used to carry the laundry.
Technical data
Dimensions (DxWxH) 60 x 60 x 85 cm (height adjustable)
Weight approx. 45 kg
Max. capacity 9 kg
Condensation container 4.2 l
Connection voltage 220-240 V
Connected load 2100-2800 W
Fuse protection 10 A / 16 A
Ambient temperature 5-35°C
Product number
Production number
Inside of door
The rating plate can be found on the back of the dryer.
Power consumption when switched off 0.10 W
Power consumption when ready for use (left-on mode) 1.00 W
ʠ
Drum interior light (depending on model): The drum lights up after the door is opened and after the programme starts, and switches off
automatically.
WZ
11410
WZ
20500
Consumption values table (The value on the label is achieved at the maximum heat setting.)
Programme
Spin speed which
is used for spinning
the laundry
Duration** Energy consumption**
cottons 9 kg 4.5 kg 9 kg 4.5 kg
10 A 16 A 10 A 16 A 10 A 16 A 10 A 16 A
cupboard dry* 1400 rpm 152 min 122 min 82 min 65 min 4.36 kWh 4.36 kWh 2.32 kWh 2.32 kWh
1000 rpm 172 min 142 min 93 min 75 min 5.23 kWh 5.23 kWh 2.78 kWh 2.78 kWh
800 rpm 192 min 162 min 104 min 85 min 6.02 kWh 6.02 kWh 3.20 kWh 3.20 kWh
Ô iron dry*
1400 rpm 127 min 105 min 68 min 53 min 2.61 kWh 2.61 kWh 1.39 kWh 1.39 kWh
1000 rpm 149 min 126 min 79 min 63 min 4.01 kWh 4.01 kWh 2.13 kwh 2.13 kwh
800 rpm 166 min 146 min 90 min 74 min 4.50 kWh 4.50 kWh 2.39 kwh 2.39 kwh
synthetics 3.5 kg 3.5 kg
cupboard dry* 800 rpm 52 min 46 min 1.42 kWh 1.42 kWh
600 rpm 65 min 56 min 1.74 kWh 1.74 kWh
For testing in accordance with applicable standard EN61121 the dryer shall be used with external drain set.
* Programme setting for testing in accordance with the applicable EN61121 standard.
** The values may differ from those specified, depending on the type of fabric, composition of laundry to be dried, residual moisture in the fabric,
the degree of dryness that has been set and the amount of laundry being loaded.
Most efficient programme for cotton fabrics
The following "standard cottons programme" (identified with ) is suitable for drying normal, wet cotton laundry and is most efficient in terms of
its combined energy consumption for drying wet cotton laundry.
Standard programme for cottons in accordance with current EU regulation 932/2012
Programme Load Energy consumption Programme duration
cottons cupboard dry 9 kg/4.5 kg
10 A 16 A 10 A 16 A
5.23kWh/2.78 kWh 5.23kWh/2.78 kWh 172 min/93 min 142 min/75 min
Programme setting for testing and energy labelling in accordance with Directive 2010/30/EU.
11
What to do if ...
Turn the programme selector to (Off) and remove the mains plug from the socket.
ʠ
The inicio/pausa (start/pause)
indicator light does not light up.
Mains plug plugged in?
Programme selected?
Check the socket fuse.
ʠ
The display panel light and
indicator lights (depending on
model) go out and
the inicio/pausa (start/pause)
indicator light flashes.
Energy-saving mode is activated a see the separate
Energy-saving mode instructions.
ʠ
The display panel switches off. The appliance goes into the sleep mode after activating
(Finished in) option apage 5.
ʠ
The È (Condensate container)
indicator light flashes.
Empty the condensate container apage 4.
Press the
inicio/pausa (start/pause) button to reset the
displayed indication and then press the inicio/pausa
(start/pause) button again to restart the appliance if
necessary.
If featured, check the hose for condensation outlet.
ʠ
¡(Fluff filter/Heat exchanger)
indicator light flashes.
Clean the fluff filter a page 4.
Press the inicio/pausa (start/pause) button to reset the
displayed indication and then press the inicio/pausa
(start/pause) button again to restart the appliance if
necessary.
Clean the heat exchanger a page 8.
ʠ
Dryer does not start. inicio/pausa (start/pause) button selected?
Door closed?
Programme set?
After-sales service
If you cannot rectify the fault yourself (e.g. switching off/on) a What to do if..., page 11/12,
please contact our after-sales service. We will always find an appropriate solution and avoid
unnecessary visits by engineers.
The contact details of your local after-sales service can be found in the enclosed after-sales
service directory.
– GB 0344 892 8999 (Calls charged at local or mobile rate.)
– IE 01450 2655 (0.03 € per minute at peak. Off peak 0.0088 € per minute.)
Please provide the after-sales service the product number (E no.) and the production number
(FD) of the appliance.
Product number Production number
You can find this information:
inside the door* / in the opened service flap*
and on the rear of the appliance.
*depending on the model
Trust the expertise of the manufacturer. Contact us for assistance. In this way, you can rest
assured that the repair will be carried out by trained service technicians using original spare
parts.
