Siemens Z4.0

71
Congratulations on your purchase of a Siemens Z4.0
vacuum cleaner.
This instruction manual describes various Z4.0 models,
which means that some of the equipment features and
functions described may not be available on your
model. You should only use original Siemens
accessories, which have been specially developed for
your vacuum cleaner, to achieve the best possible
vacuuming results.
Please keep this instruction manual. When passing the
vacuum cleaner on to another person, please also hand
over this instruction manual.
Fold out the picture pages.
Your vacuum cleaner
1 Adjustable floor tool (with locking collar)*
2 Hard-floor brush (with locking collar)*
3 TURBO-UNIVERSAL® brush for floors*
4 Hose hand grip
5 Flexible hose
6 Telescopic tube with sliding switch
(and locking collar)*
7 Telescopic tube with adjusting sleeve
(and locking collar)*
8 Power cord
9 Parking aid
10 Locking lever
11 Exhaust grille
12 Dust bag
13 Exhaust filter*
14 Motor protection filter, washable
15 Carrying handle
16 Dust bag compartment lid
17 Dust bag change indicator*
18 Storage aid (on underside of appliance)
19 On/off button and power controller
20 Upholstery nozzle*
21 Crevice nozzle*
Replacement parts and special
accessories
A Replacement filter pack
Filter type G (VZ41AFG)
For best performance: GXXL (VZ41AFGXXL)
Contents: 4 dust bags with seal
1 micro-hygiene filter
http://www.dust-bag-siemens.com
B TURBO-UNIVERSAL® brush for upholstery VZ46001
All-in-one brushing and vacuuming of upholstered
furniture, mattresses, car seats, etc. Especially suita-
ble for picking up pet hair. The brush roller is driven
by the suction air flow of the vacuum cleaner.
No separate electric connection is needed.
C TURBO-UNIVERSAL® brush for floors VZ102TBB
All-in-one brushing and vacuuming of rugs and car-
pets, and for all floor coverings. Particularly suitable
for vacuuming up pet hair. The brush roller is driven
via the suction air flow of the vacuum cleaner.
No separate electric connection is needed.
D Hard floor brush VZ123HD
For vacuuming hard floors
(parquet, tiles, terracotta, etc.)
Initial use
Figure
● Push the hand grip onto the flexible hose and lock it
in place.
● To remove the hand grip, press the two catches
together and pull out the flexible hose.
Figure
a)Push the flexible hose adapter into the air intake
opening in the vacuum cleaner lid until it locks in
place.
b)To remove the flexible hose, press the two catches
together and pull out the hose.
Figure
a)Push the hand grip into the telescopic tube. To
remove it, turn the hand grip slightly and pull it out of
the tube.
b)Push the hand grip into the telescopic tube until it
engages.To release the connection, squeeze the
collar sleeve and pull the handle out.
Figure
a)Insert the telescopic tube into the connecting piece
of the floor tool. To release the connection, turn the
tube slightly and pull it out of the floor tool.
b)Push the telescopic tube into the connecting piece of
the floor tool until it locks in place. To release the
connection, press on the locking collar and pull out
the telescopic tube.
Figure
● Move the adjusting sleeve/slider button in the direc-
tion of the arrow to unlock the telescopic tube and
adjust it to the length required.
Figure
● Holding the power cord by the plug, pull out to the
required length and insert the plug into the mains
socket.
2
3*
4*
5
1
6
en
*
depending on model
