Sight mark Twilight - Technical Specifications

2
FEATURES:
• Day time/night time use
• Brightness control
• Built-in IR Illuminator
• Video output
• Ergonomic and compact
TECHNICAL SPECIFICATIONS:
Magnication 3.5x 5x 7x
Objective Lens diameter 42mm 50mm 50mm
Resolution, lines/mm 36mm 36mm 36mm
Angular eld of view 5º 4º 2.5º
Sensor Type CCD CCD CCD
Max. Viewing range 100m 140m 150m
Eyepiece adjustment ±5 ±5 ±5
Operating voltage 3(2xAA) 3 (2xAA) 3(2xAA)
Output video signal CCIR/EIA CCIR/EIA CCIR/EIA
Operating time (IR
on/o)
6/4hr 6/4hr 6/4hr
Dimensions 152x94x60mm 170x94x60mm 170x94x60mm
Weight 12.3oz 12.7oz 12.7oz
INCLUDES:
• Carrying Case
• Hand Strap
• Lens Cleaning Cloth
SM18012
SM18013
SM18014
