PARTS LIST, SEALER ASSEMBLY
KEY QTY. PART NO. DESCRIPTION
1 1 424137 Mounting plate
2 1 424136 Piston
3 4 276495 Flexloc nut, M8 (w/nylon)
4 2 424214 Washer
5 1 422858 O-ring #112 Quattro
6 1 424129 Ram
7
2 424126 Side plate (114)
2
424211 Side plate (34)
8 4 424128 Sealer link
9 1 424130 Ram pin
10 2 424131 Link pin
11
2 424134 Jaw (114)
2 424213 Jaw (34)
12 2 424127 Notcher (114)
2 424212 Notcher (34)
13 2 424132 Jaw pin
14 1 424133 Notcher spacer
15 3 280878 SHCS, M8 X 35 (full thread)
16 3 280807 Lockwasher, M8
17
1 424138 Boot
18 1 424202 O-ring #243
19 1 424203 O-ring #342
! Standard hardware parts may be obtained
from local hardware suppliers.
! When ordering parts, please show tool model,
part number, and name.
! Recommended spare parts are underlined and
should be stocked.
! This tool has metric fasteners.
To Next Page
