© 2000–2021 signotec GmbH signotec Delta user manual Page 7 of 19
6.2. Back side
1 Pen holder (horizontal) 7 Foldout support
2
Pen with cord
(attached to the device and pen)
8 Device designation
3 USB cable 9 Item number
4
Mounting fixture for
a vertical pen holder
10 Hardware revision number
5 Tension relief for USB cable 11 Barcode with unique serial number
6 Micro-USB port 12 VESA mounting fixture (75 × 75 mm)
