Specifications
Package Contents
• DisplayPort 1.2 to 3-Port HDMI MST Splitter
• Micro-USB power cable
• User Reference Guide
System Requirements
• PC with an available DisplayPort 1.2 connection
• Windows
®
10 / 8.1 / 8 / 7 (32-/64-bit)
Chipset STDP4320
Compli ance DisplayPort 1.2a
Output signal HDMI
Maximum resolution 3840x2160 @30Hz
Audio 7.1-ch surround audio
Disp lay mode
Mirror, Extended, and Panoramic video wall
mode
Connectors
Input: 1x 20-pin, DisplayPort, Male
Output: 3x 19-pin, HDMI , Female
Power: Micro-USB, Female
Housing material Aluminum
Built-in cable length 10.24" (overall)
Dimensions 4.13" (W) x 0.65" (H) x 2.60" (D)
Weight 0.28lbs
