Keep these instructions in a safe place!
After installation of the tubular motor attach these
instructions to the cable for the electrician.
Optimal use of the radio signal
• Do not bend the antenna.
• Do not shorten or extend the antenna.
• If reception is poor, adjust the antenna.
• Install the antenna so that it is as exposed as possible.
• The minimum distance betweeen two radio-controlled drives
must be at least 15 cm.
Intended use
• Please ensure that the radio installations are not operated in
areas of increased possible interference. (e.g. hospitals,
airports ...).
•
The radio control is only permitted for devices and units with which
a functional interference in hand-held/wall-mounted transmitters or
receivers poses no danger for persons, animals or materials or
where this risk is covered by other safety appliances.
• The operator has no protection whatsoever from interferences
by other radio emitters and local terminals (e.g. also from radio
installations), that are normally used on the same frequency
range.
• Only use radio receivers with equipment and units approved by
the manufacturer.
Tubular motor – 20 series
868 MHz
Device functions:
• Blind protection (torque limiting)
• Commissioning of the tubular motor using assembly cable or
radio transmitter
As-delivered condition (commissioning mode)
• Setting end positions
Check the following before installation:
• The tubular motor is only capable of operation as installed.
• Only perform connecting work with the power turned off.
• The blind must be attached to the winding shaft.
• The profile tube must have sufficient clearance from the motor
tube.
• Make sure there is sufficient axial play (1–2 mm)
Important safety instructions!
Observe the following instructions.
Risk of injury due to electrocution.
The connections to the 230 V mains must be made
by authorised specialist personnel.
Check the system regularly for wear or damage.
The regulations of the local energy supply company
as well as the regulations for wet and damp rooms
according to VDE 0100 must be followed when
making the connections.
Only use unmodified original electrical parts.
Do not drill in the area of the tubular motor!
Keep people away from the system until it is
stationary.
When working on the system (servicing, cleaning
windows etc.), always disconnect the system from
the mains supply.
Installation
Observe the following installation instructions!
–
The tubular motor must be fixed in such a way that
it does not endanger personnel.
– Before installing the tubular motor, all lines and
equipment, which are not required for operation,
must be removed from the site.
– During installation, during operation and when
work is carried out on the system, the option to
separate all three poles from the mains must
always exist (a two-pole switch with minimum
3 mm contact gap or all-pole main switch).
– If the tubular motor is controlled by a switch with
OFF pre-setting (dead man’s button), the momen-
tary contact switch must be fitted at a height of
more than 1.50 m and separated from the moving
parts.
The travel range of the systems must always be
visible during operation.
– Moving parts in a tubular motor, which are below
2.5 m, must be guarded.
– Set torque and set operating time must be
adapted to the requirements of the product which
is driven.
– Please note the technical data on the type plate.
– Please note that with this tubular motor
(Typ S and M tubular motors) the smallest inner
tube diameters corresponds with 36 mm and
46 mm.
– The tubular motor must be installed so that it
cannot get wet.
– Do not install tubular motors in surroundings
which are at risk of explosion or in mobile
appliances (e.g. motor vehicles).
– Keep children away from the (remote) control
unit.
GB
