Osiris-Jaegar – Installer Guide
Appendix 6 – Camera and Lens Options
Lens options - PAIR2
Osiris Open Platform
Version n.nnn (xxxx) xx
SN: FFFFFFFF POST: 000000000
Enhanced view
Stabilizer
Fog reduction
Haze reduction
Backlight comp
Night mode
Contrast
Tone
Brightness
Gamma
DSP Reset
Zoom overshoot 3321
Focus overshoot 1233
Zoom Tolerance 22
Focus Tolerance 22
Exit menu
Enhanced view selects if the output image includes image
enhancement or is direct from the camera.
Stabilizer enables/disables the image stabilisation.
Fog reduction allows the level of fog reduction processing to be
selected.
Haze reduction allows the level of haze reduction processing to
be selected.
Backlight comp allows the selection of backlight compensation
level that is applied.
Night mode selects the night-time (darkness) enhancement level.
Contrast level can be adjusted – 0 to 30
Tone level can be adjusted – 0 to 30
Brightness level can be adjusted – 0 to 30
Gamma level can be adjusted – 0 to 20
DSP Reset causes the enhancement processor to restart.
Zoom Overshoot and Tilt Overshoot – Automatic values. These
define how much mechanical overshoot the lens control will adjust
for when changing at speed. Do Not Change.
Zoom Tolerenance and Tilt Tolerance – Automatic values. These define how much mechanical margin to
allow for when change Zoom and Focus. Do Not Change.
PAIR2 Preset Groups.
Preset Position values 130 – 139 are assigned as PAIR function presets.
These presets are masked to store the DSP values that have been set for the PAIR in the Lens Options
menu.
The Pan/Tilt/Zoom/Iris values are not stored in to these positions and so will not change when re-called.
Camera 1 options – Samsung
Osiris Open Platform
Version n.nnn (xxxx) xx
SN: FFFFFFFF POST: 000000000
Flip Horizontal Off
Flip Vertical Off
Sharpen Off
Sharpen level 0
Exit menu
Example functions shown for illustrative purposes only –
Samsung SHC-745P.
Example values shown.
Silent Sentinel SilSen DN145003 - 1.2b (Fork)
19
