7
OPERATING INSTRUCTIONS
Ice Maker Performance Mode Instructions (cont)
Performance
Mode
Instructions
Suitable situation
Operation instruction
Drain pump mode.
Unnecessary water
will be forced out
the drain by the
pump.
The height of drain
hole in the room is
between 10cm~150cm
Ref: Fig.A & Fig.B & Fig.C (page 5)
Drain Nut and Switch
Condition
drain nut (front) (3) + drain seal (front) (4)
drain nut (back) (7) + drain seal (back) (6)
drain cap (11)
drain cap (12)
drain pump switch (8)
lock
open
open
lock
on
1. Please insure the drain nut and switch are in the
above condition;
2. Use a drain tube with a length of (4 feet). Connect one
side to the drain pump outlet (10) and the other to the
drain hole. Please insure the connection is tight to
avoid water leakage.
NOTE:
1. If you take out the bottom board of the ice box, it will make the volume of the ice box larger and
therefor will keep more ice.
2. If your operating using the “Manual drainage system mode”, ice will restrict drain water from flowing out.
10cm - 150cm
CONTROLS OF THE ICE MAKER
The Ice Maker should be placed where the ambient temperature is between 5-35°C (41-95°F). If the ambient
temperature is above or below this range, the performance of the unit may be affected.
