3
compass cover
luminous points
base plate
black clinometer
pointer
magnetic needle with
red north
2X magnifier
scale in mm
sight
mirror
sighting line
index pointer
orienting arrow with red
north end
meridian lines
liquid filled capsule
bezel with
2º graduations
scale in inches
