NATO STOCK NUMBER
6605-21-854-7751 / 6605-99-520-4379
ACCESSORIES
Lanyard
PRODUCT FEATURES
Type of compass Silva 1-2-3 System Mirror sighting compass
Compass capsule / needle
Sighting System Mirror
Magnifying lens Yes
Declination adjustment Declination adjustment
Clinometer Yes - model 15 TDCL
Illumination / active time
after activation in light Yes
Luminous compound
Silicon friction feet Yes
Other Patented red/black N/S lines in capsule
This original mirror sighting compass is used by
defence forces all over the world. It has Romer scales
with plotting holes for finding and marking GPS
coordinates on the map and rubber feet so it won’t slide
on the map. Expedition 15 TDCL has a built in adjuster
for magnetic declination and it can also be used on
maps without meridians.
Military Equipment
SPECIFICATIONS
Available graduations 6400/360
Resolution degrees / mils 2 / 50
Measuring scales on
base plate mm, inch
UTM position plotting
scales (Romer scales) 1:25k, 1:50k
Settling time from 90
degree angle within +/- 3 deg 2.7 sec
Settling time from 90
degree angle to complete rest 5 sec
Accuracy +/- 1 degree (17.8 mils)
Waterproof IP68 - (more than 100 m)
Altitude use 5000m@-15 C
Impact resistance 30g in XYZ directions and free fall from 1,5 m
height into gravel
Temperature operating range -40 to +60 C
Material Acrylic/Acetal
Size (mm) 108x63x20
Weight g 88
Art.No’s.
36814-4511 COMPASS 15T-360/6400 Green
36818-4511 COMPASS 15TDCL-360/6400 Green
36818-4411 COMPASS 15TDCL-6400 Green
Compasses
Expedition 15
