6
NATO STOCK NUMBER
-
ACCESSORIES
Lanyard
PRODUCT FEATURES
Type of compass Silva 1-2-3 System Mirror sighting compass
Compass capsule / needle -
Sighting System Mirror
Magnifying lens No
Declination adjustment Decl scale in capsule
Clinometer No
Illumination / active time
after activation in light Yes / 6 hours
Luminous compound Everglow™
Silicon friction feet No
Other Dryflex™, tactile grip ring
Patented red/black N/S lines in capsule
Ranger 16 is a perfect all-round mirror sighting compass
for navigation on land or at sea. Used by both infantry
and artillery as a soldier’s or officer’s compass. Mirror
sighting increases accuracy in taking out bearings and
the transparent base plate makes map work easier.
Military Equipment
SPECIFICATIONS
Available graduations 6400/360 (360 inside the capsule)
Resolution degrees / mils 2 / 50
Measuring scales on
base plate mm, inch
UTM position plotting scales
(Romer scales) No
Settling time from 90
degree angle within +/- 3 deg 2.7 sec
Settling time from 90
degree angle to complete rest 5 sec
Accuracy +/- 1 degree (17.8 mils)
Waterproof IP68 - (more than 100 m)
Altitude use 5000m@-15 C
Impact resistance 30g in XYZ directions and free fall from 1,5 m
height into gravel
Temperature operating range -40 to +60 C
Material Acrylic/Acetal
Size (mm) 90x59x16
Weight g 53
Art.No. 36820-4711 Compass Ranger 16 Green
Compasses
Ranger 16
