Silver Cross Balmora - Fitting the handle; Attach S-shaped metal bars; Secure the gripping handle

2
1.1
1.2
Contents
First check all your parts have been
supplied. Your Balmoral pram includes:
a) Body & Chassis
b) 2 x S-shaped metal bars
c) Handle
d) Hood
e) Apron
f) Tray (including 2 brackets)
g) Liner
h) Mattress with cover
i) After Care Kit
- Care instructions
- Brush
- Cloth
- Spanner
j) Certificate of Authenticity
k) 5 year guarantee application card
Fitting the handle
1.1 Attach the two S-shaped metal bars (C)
with the flat side against the body onto
the threaded bolts. Then attach the
sleeved nut ‘A’ onto the outer most bolt
(do not tighten until dome nut ‘B’ has
also been attached). Attach dome nut
‘B’ onto the inner most bolt. Do this on
both sides. Do not fully tighten until the
handle has been attached.
1.2 Attach the gripping handle onto the
two S-shaped metal bars; ensure the
washer is between the dome bolt and
the S-shaped metal bars. Tighten using
the spanner enclosed in your After Care
Kit. Now tighten all nuts until the handle
is secure.
A B
C
