Model:
Product Type:
SE130
PARTS BREAKDOWN
Parts List
AIR BELT SANDER
3/8" x 13"
SE130-01A
SE130-01
SE130-02
SE130-03
SE130-04
SE130-05
SE130-06
SE130-07
SE130-08
SE130-09
SE130-10
SE130-11
SE130-12
SE130-13
SE130-14
SE130-15
SE130-16
SE130-17
SE130-18
1A
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Idle Pulley Assembly
Idle Pulley
Ball Bearing (684zz)
Idle Pulley Screw
Bracket 10
Set Screw (M3×8)
Phillips Screw
Spring
Tension Bar
Spring Pin ( 3×10)
Stopper Pin
Guard Bushing
Tension Spring
Guard Sub Ass'y 11
Head Cap Screw (M5×15)
Dust Cover
Shoe 10
Hexagon Socket Headless Set Screw
Stopper Spring
1Set
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
SE130-37
SE130-38
SE130-39
SE130-40
SE130-41
SE130-42
SE130-43
SE130-44
SE130-45
SE130-46
SE130-48
SE130-49
SE130-50
SE130-80
SE130-100
SE130-120
SE130-54
SE130-55
37
38
39
40
41
42
43
44
45
46
48
49
50
51
52
53
54
58
Spring Pin ( 3×20)
Valve Body
O-Ring (S11.2)
O-Ring (P-9)
Valve Stem
O-Ring (P3)
Valve Spring
Air Regulator
O-Ring (P7)
External Stop Ring (STW-8)
Exhaust Diffuser
Inlet Bushing
Housing Cover
Sanding Belt 80 Grit - 10 x 330 mm
Sanding Belt 100 Grit - 10 x 330 mm
Sanding Belt 120 Grit - 10 x 330 mm
O-Ring (AS-004)
Pulley Cover
SE130-19
SE130-20
SE130-21
SE130-22
SE130-23
SE130-24
SE130-25
SE130-26
SE130-27
SE130-28
SE130-29
SE130-30
SE130-31
SE130-32
SE130-33
SE130-34
SE130-35
SE130-36
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
1
1
1
1
1
1
1
1
1
1
1
5
1
1
1
1
1
1
Stopper
Spring Pin ( 2.5×10)
Hexagon Nut (M6)
Washer (M6)
Drive Pulley
Housing
Ball Bearing (6000ZZ)
Front End Plate
Spacer
Rotor
Parallel Key Both Ends Round 4×4×9.5
Rotor Blade
Cylinder
Rear End Plate
Ball Bearing (608zz)
O-Ring (S38)
Cap
Throttle Lever
Index Part No. Description Qty Index Part No. Description Qty Index Part No. Description Qty
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
504
