1
Manufactured especially for Dunkin Donuts
MODEL: SKDC12-ESUS1
Specifications Subject to Change Without
Notice.
1600 Xenium Lane North, Minneapolis, MN 55441-3787
Phone (763) 923-2441
Fax (763) 553-1209
www.silverking.com
FORM NO. 45185 REV D 12/2019
Technical Manual
and
Replacement Parts List

Questions and Answers

  • S
    Stephen EricksonAug 12, 2025
    Why does my Silver King SKDC12-ESUS1 Commercial Food Equipment compressor run constantly?
    • K
      Kathleen WoodAug 13, 2025
      If the compressor in your Silver King Commercial Food Equipment runs too much or constantly, several factors could be responsible. Abnormally high room temperature can cause this issue, so reducing the room temperature might help. Make sure that all containers are correctly inserted and filled with product. Other potential causes include a system undercharge due to leaks or from the factory, a system overcharge, a dirty system, or a restricted filter drier or capillary tube. For these issues you should call a service technician.
  • X
    xwelchAug 19, 2025
    Why is my Silver King SKDC12-ESUS1 compressor short cycling?
    • C
      Christopher RoweAug 19, 2025
      If the compressor in your Silver King Commercial Food Equipment is short cycling, it could be due to erratic control thermostat, faulty relay, or low voltage. Contact your power company and confirm that voltage fluctuation does not exceed 10% plus or minus from the nominal rating. Another cause may be that the compressor draws excessive wattage. For erratic control thermostat, faulty relay, and excessive wattage you should call a service technician.
  • M
    Michael WaltersAug 25, 2025
    Why is my Silver King Commercial Food Equipment so noisy?
    • B
      Brandon BurchAug 25, 2025
      If your Silver King Commercial Food Equipment is noisy, it could be due to several reasons. Tubing may be vibrating, or there could be internal compressor noise. The compressor might also be vibrating on the cabinet frame. In all of these cases, you should call a service technician.
  • J
    Jason GonzalezAug 30, 2025
    What to do if my Silver King SKDC12-ESUS1 is out of calibration after refill?
    • M
      Mrs. Jenna BurnsAug 30, 2025
      If your Silver King Commercial Food Equipment is out of calibration after a refill, it might be because the containers are not in the correct positions. Check the container positions (L, C, R) to ensure they are properly placed.
  • Q
    qfrazierNov 6, 2025
    How to fix a Silver King Commercial Food Equipment compressor that will not run?
    • C
      Cynthia GreeneNov 6, 2025
      Several factors can cause the compressor in your Silver King Commercial Food Equipment not to run. First, ensure the circuit breaker or fuse is working. Check that the service cord is properly plugged into the wall receptacle. Low voltage can also cause the compressor to cycle on overload, so contact your power company to confirm voltage fluctuation does not exceed 10%. Verify that containers are correctly positioned (L, C, R). Also, ensure the power switch is in the “On” position, and the power cord is securely connected to the unit. If these steps don't resolve the issue, it may be due to an inoperative control, a stuck compressor, open compressor windings, a stuck-open compressor overload, a loose relay lead, a loose or inoperative relay, or faulty cabinet wiring, all of which require a...
