SHSS 18 B1■ 10
│
GB
│
IE
3) Start by pulling the EPA filter 5 and then
the coarse filter
6 out of the dirt container 7
(Fig. 4). Tap out both parts over a rubbish bin
or similar. If necessary, you can rinse out the
EPA filter
5 with fresh water. Allow it to air
dry fully afterwards.
Fig. 4
4) Empty the dirt container
7 into the rubbish
bin or similar.
5) First re-insert the coarse filter 6 and then the
dry EPA filter 5.
6) Replace the dirt container 7 onto the hand
element 3 by first pushing the lower catch on
the hand element 3 into the recess on the dirt
container 7. Then, press the upper part of the
dirt container 7 onto the hand element 3
until the dirt container 7 clicks into place
and sits firmly.
Cleaning the appliance
Wipe the appliance with a damp cloth. For stub-
born dirt, add a little mild detergent to the cloth. En-
sure that the appliance is completely dry before
using it again.
Cleaning the rotary brush
The rotary brush r should be checked regularly
for blockages; any hair, threads or dirt should be
removed. Remove the rotary brush
r as follows:
1) Turn the floor nozzle upside down.
2) Push the catch on the cover plate towards
the symbol and remove the cover plate
(Fig. 5).
3) Remove the rotary brush
r.
4) Remove any dirt (on both sides of the brush
bristles) and clean the rotary brush
r.
To do this, take a damp cloth and wipe the
individual bristle bundles from the inside to
the outside.
5) To replace the rotary brush
r, first push the
broad end onto the drive shaft so that the
rotary brush
r hooks into place.
6) Then, push the other end into the mount so
that the rotary brush
r sits straight in the floor
nozzle.
7) Reattach the cover plate until it clicks firmly into
place. The cover plate locks automatically as
the latch moves towards the symbol (Fig. 5).
Fig. 5
Storage
■ When you are not using the appliance, place
it on the cradle o.
■ Store the 2-in-1 crevice and brush attachment
z in the accessory compartment a.
■ Alternatively, you can put the brush nozzle and
crevice nozzle
into the accessories holder s
individually or together.
■ Store the appliance in a dust-free and dry
location.
To Next Page
