14 GB/IE
Selecting the chime
Note: The doorbell has 16 different chimes.
Press the melody selection button
4
. The first audible signal
sounds.
Press the melody selection button
4
again to move on to the
next audible signal.
Repeat this process until you have selected your desired audible
signal. The last-selected audible signal is automatically stored.
The procedure for connecting the
transmitter to existing bell system or
existing doorbell button
Remove the holder
12
by pressing the lock
11
from the back of
the transmitter and remove the rubber cover
15
(see fig. C1).
Open the inner cover
14
by cross head screw driver (see fig. F).
Remove the plastic clip of cable exit hole
18
with a flat head
screw driver (see fig. G).
Insert the cable through cable holder
19
and cable exit hole
18
(see fig. H).
Connect cable to the terminals A and C (for connecting to exist-
ing doorbell) or the terminals B and C (for connecting to existing
door bell button) by using screw driver (see fig. H).
