Connectors and Controls
EN
The following table lists the available terminals:
No. Description
(5)
Main power switch (On/Off)
Use this swivel-type switch to completely power off your TV set so that it fully stops con-
suming any energy at all. The power indicator (1) on the front panel stops lighting after
you power it off.
(6)
AC IN terminal
To connect the power cord.
(7)
USB port
You may not connect any external USB devices to this port. It is reserved for servicing
purposes only.
(8)
PC Audio input
If you want to use your TV set as a PC monitor and the PC is connected to the input jack
(19), you can input the PC audio signal here. Then the sound generated by the PC can be
listened to through the loudspeakers of your TV set.
(9)
Component Video input (Y, Pb/Cb, Pr/Cr)
Here you can connect external devices that feature Component Video output connectors
(for instance a DVD player or other high-end playback equipment, etc.). To do this you’ll
need a Component Video cable (not included in the package).
(10)
Component audio input
You will need to connect the audio cable from external devices (such as a DVD player or
other playback equipment) to these terminals if you are going to input the video signal via
the Component Video input terminals (9). Then the sound can be listened to through the
loudspeakers of your TV set.
(11)
Audio Output
The audio signal is available for output here. For instance, you can connect your TV set to
an amplier or stereo home cinema to enjoy the sound over the external sound system.
(12)
Headphones output
Here you can connect headphones to enjoy superior listening without disturbing other
people.
(13)
Antenna input
Here you connect your TV antenna (indoor or outdoor antenna or cable TV network ca-
ble).
(14)
SCART2
Here you can connect external devices that also feature a SCART connector (for instance
a VCR, DVD player etc.). To do this you’ll need a SCART cable (not included in the pack-
age).
(15)
SCART1
Here you can connect external devices that also feature a SCART connector (for instance
a VCR, DVD player etc.). To do this you’ll need a SCART cable (not included in the pack-
age).
(16)
Audio Input
Here you can input the audio signal from external devices (for instance a DVD player or
other playback equipment). Then the sound can be listened to through the loudspeakers
of your TV set.
