2) Select a suitable installation location for the wall bracket :
It must be possible to remove the handheld vacuum cleaner easily and there
must be an accessible mains power socket for the mains adapter .
3) Drill two holes about 34 mm apart. Use the wall bracket to mark the holes,
to ensure the correct spacing. The drill holes must be suitable for 5 mm wall
plugs.
4) Push the wall plugs into the holes and then screw the wall bracket firmly
into place using the screws.
5) You can place the nozzles on the accessories holder on the side.
6) Connect the mains adapter to a mains power socket.
Charging
NOTE
► Ensure that the on/off switch has been pushed back (and thus the appli-
ance is switched off) before starting the charging process.
■ Place the handheld vacuum cleaner from above into the wall bracket so
that the barrel plug slips into the socket on the handheld vacuum cleaner.
The charge indicator lamp lights up red and the charging process begins.
■ When charging is complete, which can take around 5 hours with fully dis-
charged batteries, the appliance automatically switches to a trickle charge
(maintenance function). The charge indicator lamp lights up green.
Nevertheless, in order to avoid possible damage to the batteries, do not
leave the appliance permanently connected to the mains adapter .
■ Do not recharge the batteries again until the handheld vacuum cleaner's
suction power becomes appreciably weaker and the charge indicator lamp
flashes green.
NOTE
► If the handheld vacuum cleaner is deep-discharged, the charge indicator
lamp flashes alternately red and green (approx. 1 minute). In this case,
switch off the appliance and start charging.
► The handheld vacuum cleaner can also be charged directly via the mains
adapter . To do this, remove the barrel plug with a slight twist from
the wall bracket and insert it into the socket on the handheld vacuum
cleaner.
