24 GB/IE
1
LED Status
2
LED LAN
3
RESET button (reset and pairing)
4
LAN port (RJ45 Ethernet)
5
Micro USB port
POWER DC5V 1A
6
Wall mounting hole
(back side, not illustrated)
7
Network cable
8
USB type A plug
9
USB cable
10
Micro USB plug
11
Metal pin
12
Screw (x2)
13
Dowel (x2)
14
Mounting template
15
USB power adaptor
Not illustrated:
16
Quick start guide
17
Safety instructions
Technical data
Gateway
USB input voltage/current 5 V , 1 A
Frequency band 2.4 to 2.485 GHz
Max. transmitted power 13 dBm
Communication protocol ZigBee 3.0
Reception range/angle approx. 70 m/360° (free area)
Operating temperature +5 to +35 °C
Operating humidity 10 to 70 %
Storage temperature 0 to +45 °C
Measurements approx. 89 x 89 x 23.5 mm
Weight approx. 78 g
