Checking the X-axis vial:
1. Position the Rotary Laser Level Unit approximately 10m away from the wall, ensuring that the X
Vial (10) is facing the wall
2. Turn the power on so that the Rotary Head (2) spins to create a line on the wall
3. Adjust the X Axis Levelling Screw (6) until the laser line matches the line you have drawn on
the wall
4. If the bubble is not in the centre of the X Vial (10), use the Screwdriver (11) supplied to adjust the
vial until the bubble is centred
Checking the Y-axis vial:
1. Turn the unit through 90° so that the Y Vial (4) is facing the wall
2. Repeat procedure as above, adjusting the Y Axis Levelling Screw (7)
Operation
Levelling
• Set up your rotary laser level in accordance with guidance in ‘Before Use’ section
• Ensure that the rotary laser is level by checking the vials and adjusting the levelling screws.
See ‘Calibrating the Laser Level’ for guidance
• Turn power on and use the control button to establish the correct speed
• Mark the desired positions
Plumbing
• Set up your rotary laser level in accordance with guidance in ‘Setting Up’ section
• Ensure that the rotary laser is level by adjusting the Y Axis Levelling Screw (6) until the bubble
is centred
• Turn power on and use the Control Button (8) to establish the correct speed
• Mark the desired positions
• It is also possible to operate the unit manually: switch on the unit and turn the unit by hand until
the laser beam is aligned with your target
Accessories
• A full range building accessories is available from your Silverline stockist
Maintenance
Cleaning
WARNING: ALWAYS wear protective equipment including eye protection and gloves when
cleaning this tool.
• Keep your tool clean at all times. Dirt and dust will cause internal parts to wear quickly, and
shorten the device’s service life
• Clean the body of your machine with a soft brush, or dry cloth
• Never use caustic agents to clean plastic parts. If dry cleaning is not sufcient, a mild detergent
on a damp cloth is recommended
• Water must never come into contact with the tool
• Ensure the tool is thoroughly dry before using it
• If available, use clean, dry, compressed air to blow through the ventilation holes
(where applicable)
Storage
• Store this tool carefully in a secure, dry place out of the reach of children
Disposal
Always adhere to national regulations when disposing of power tools that are no longer functional
and are not viable for repair.
• Do not dispose of power tools, batteries or other waste electrical and electronic equipment
(WEEE), with household waste
• Contact your local waste disposal authority for information on the correct way to dispose of
power tools
